12 Core YY Control Cable

12 Core YY Control Cable is a flexible mulit-core cable with class 5 flexible annealed plain copper conductors, PVC insulation, and a grey PVC sheath. YY Cable is used in fixed installations or flexible use in conditions with light mechanical stress. It can be used in dry and moist area’s including outdoors when mechanically protected. 12 Core YY Control Cable is widely used on production lines, conveyor systems, machine tool manufacturing and air conditioning systems.





Part No.	No. Cores	Conduct or Cross Secton Area (mm²)	Cable Cross Secton Area (mm²)	Overall Diameter (mm)	Gland Size	Cleat Size	Nominal Weight (kg/km)	Resistance of Copper Conductor (Ω/Km) at 200C
12C.75YY	12	0.75	86.54	10.5	20	5	175	26
12C1.0YY	12	1	109.3	11.8	20	5	220	19.5
12C1.5YY	12	1.5	132.66	13	20	6	305	13.3
12C2.5YY	12	2.5	193.49	15.7	25	7	535	7.98



• Ideal for space saving installations

• Highly flexible due to the short twisted conductor layers

• Versatile multi-core power and signal cables

• Ideal for indoor use where light mechanical stresses are present

• Good chemical resistance

• YY control cable has a grey PVC outer sheathing

• White numbers on the outer sheath

• These unscreened flexible multi-core cables have a voltage rating of 300/500V
