7 Core CY Control Cable

7 Core CY Control Cable also known as LiYCY Cable is a PVC insulated and sheathed Type CY Screened cable and is suitable for use as a signal and data control cable in control circuits, machine tools, computer systems, industrial plants, production lines and electronics. The tinned copper wire screen offers protection from electromagnetic interference (EMI) and reduces electromagnetic radiation (EMR).


Attribute	Value
Number of Cores	7
Cross Sectional Area	1.5 mm²
Current Rating	18 A
Outer Diameter	9.9mm
Voltage Rating	300/500 V
Sheath Colour	Grey
American Wire Gauge	16 AWG
Earth Cable	Yes
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+80°C
Oil Resistant	Yes
Sheath Material	Polyvinyl Chloride PVC
Minimum Bend Radius	Fixed – 6 x D Occasional Flexing – 20 x D
Conductor Material	Copper
Core Strands	30/0.25 mm
Screen Type	Tinned Copper Braid
Screened/Unscreened	Screened
Conductor Resistance	13.5 Ω/km
Insulation Material	PVC
Filler Material	Non-Wicking Filler



Industrial machinery and machine tools

Measurement, control and electrical applications

Food production and packaging machinery

Very suitable for oily wet areas within machine tools and transfer lines that are subject to normal mechanical stress

Outdoor use is possible within the indicated operating temperature range



High oil-resistance

Abrasion and notch-resistant

EMC-compliant

Low-adhesive surface

Resistant to hydrolysis and microbes



Single core: blue

2 core: brown & blue

3 core: brown, blue & green/yellow

4 core: brown, grey, black & green/yellow

5 core: brown, blue, grey, black & green/yellow

7 core and above: black cores with white number inc Green/Yellow
