ACSR Weasel Conductor

ACSR weasel conductor belongs to ACSR-BS215 standards. Every code has its own specification. Now I will tell you the weasel conductor size.acsr weasel conductor strands 6 aluminums and 1 steel. But their diameter is the same, and they are 2.59 mm. We can know the overall diameter is 7.77 mm. From the standard, we can know the nominal aluminum area of acsr weasel conductor is 30 mm2. When you want to buy acsr weasel conductor, you should pay attention to this point. It isn’t suitable for the standard, and it is reasonable. The total sectional area is 36.88 mm2. After the cabling, the total linear mass is 128 kg/km.

Through the test, the calculated breaking load should be 1146 daN. At the 20℃, calculate D.C. resistance should be 0.9077. When the acsr weasel conductor is working, the current rating should be 134 A.



Code name		acsr weasel conductor
Nominal aluminum area mm 2		30
Stranding structure	Al. No.	6
	Al. Dia.	2.59
	St. No.	1
	St. Dia	2.59
Sectional area of aluminum	mm 2	31.61
Total sectional area	mm 2	36.88
Overall diameter	mm	7.77
Total	kg/km	128
Calculated breaking load	daN	1146
Calculate D.C resistance at 20 ℃	Ω/km	0.9077
Current Rating	A	134



acsr weasel conductor have been widely used in power transmission lines with various voltage levels,because they have such good characteristics as simple structure,convenient installation and maintenance,low cost large transmission capacity.And acsr weasel conductor are also suitable for laying across rivers valleys and the places where special geographical features exist.



ACSR Weasel Conductor has high tensile strength. This makes it one of the finest solutions for overhead power lines, because it requires fewer support poles. There are many additional benefits, of the offered solutions. It provides high voltage as well as extra high voltage to the power lines. ACSR Weasel Conductor is extremely very simple to work with as well as maintain. Offered conductor needs less maintenance. Offered is a steel reinforced aluminum conductor of high durability.
