Pvc Sheathed Insulated Solid Flat Wire

It is suitable for cables and wires for rated AC voltage 300/500V and below for power devices, daily electrical appliances, instruments and telecommunication equipment, and can also be used for surface-mounted wires.

1. Product model: BVVB

2. Product name: copper core PVC insulated PVC sheathed flat cable

3. Number of cores: 2-3 cores

4. Nominal section: 0.75-10mm²

5. Rated voltage: 300/500V

6. Executive standard: JB8734.2-2016

7. Product use: This product is suitable for fixed wiring of power devices and electrical equipment with AC rated voltage 450/750V and below.

8. Use characteristics: The long-term allowable working temperature of the cable core should not exceed 70°C, and the laying temperature of the cable should not be lower than 0°C.

9. The allowable bending radius of the cable:

Cable outer diameter (D) is less than 25mm, should not be less than 4D

Cable outer diameter (D) The cable outer diameter (D) is 25mm and above, and should not be less than 6D

10. Flame-retardant type: Z(A, B, C)-BVVB; fire-resistant type: NH-BVVB; low-smoke halogen-free type: WDZ(B, C)-BYYB
